Product type：Graphic LCD Module
Show contents：128x64
Outline size(mm) ：54X50X6.5
Size of View Window(mm)：43.5x29
Display size(mm) ：40.92x24.92
Point spacing(mm)：0.32x0.39
Product application：Instruments
Visual angle：6H
Backlight type or brightness：white
Connection PIN Number：20PIN
Interface mode：MCU
Special instructions：Anti-static ESD 8KV
Working temperature：-20~70℃
Power supply voltage：5.0V
Driver chip model：KS0108
HTM12864F-41W-A5P is a 2.0-inch 128x64 monochrome graphic dot matrix LCD display module with white text on black background, wide temperature, 3.3V voltage, SPI interface, wide viewing angle and high contrast. All materials comply with environmental requirements RoHS standards. This module is widely used in various instruments, smart devices, etc., and is suitable for a variety of microcontroller development platforms such as 8051, PIC, AVR, ARDUINO, ARM and Raspberry Pi.
